Zebra ZT600/ZT610/ZT620 Rfid Industrial Printer
Zebra ZT600/ZT610/ZT620 Rfid Industrial Printer
- Model: Zebra ZT600/ZT610/ZT620
- Printing Method: Thermal Transfer and Direct Thermal
- Printing Speed:
- ZT610: Up to 14 inches (356 mm) per second
- ZT620: Up to 12 inches (305 mm) per second
- Interface: USB 2.0, RS-232 Serial, Gigabit Ethernet, Bluetooth 4.0
We've streamlined our ordering process to ensure you get your RFID solution quickly and efficiently.
What You'll Need to Provide
- Current inventory management processes
- Expected read volume and tag density
- Environmental conditions and physical space
- Integration requirements with existing systems
আপনার RFID সমাধান দ্রুত এবং দক্ষতার সাথে পেতে আমরা আমাদের অর্ডার প্রক্রিয়াটি সহজ করেছি।
আপনার যা প্রদান করতে হবে
- বর্তমান ইনভেন্টরি ব্যবস্থাপনা প্রক্রিয়া
- প্রত্যাশিত পঠন ভলিউম এবং ট্যাগ ঘনত্ব
- পরিবেশগত অবস্থা এবং ভৌত স্থান
- বিদ্যমান সিস্টেমের সাথে একীকরণের প্রয়োজনীয়তা
Key specification
Detailed technical specifications that make this product reliable, high-performing, and widely trusted
| Printing Method |
Thermal Transfer and Direct Thermal |
|---|---|
| Interface |
USB 2.0, RS-232 Serial, Gigabit Ethernet, Bluetooth 4.0 |
Zebra ZT600 Series: Next-Generation Industrial RFID Printers for High-Volume Tag Encoding
High-capacity distribution centers, garments export facilities, and heavy manufacturing plants in Bangladesh need tag printers that run 24/7. The Zebra ZT600 Series RFID Industrial Printers (comprising ZT600, ZT610, and ZT620) are engineered to deliver high-speed, continuous RFID label printing and chip encoding. They combine rugged durability with advanced user controls, ensuring clear text, barcodes, and encoded RFID chips for all your shipping and tracking needs.
High Printing Speeds and Industrial Mechanical Precision
The ZT610 prints up to 14 inches per second (ips) at 203 dpi, while the wide-format ZT620 outputs up to 12 ips at 300 dpi, handling massive print runs without slowdowns. Housed in an all-metal chassis, they feature a side-loading mechanism for fast media changes and standard Gigabit Ethernet, USB 2.0, RS-232, and Bluetooth 4.0 connectivity for straightforward network installation.
Enterprise System Integration and Security
With Zebra’s Link-OS operating system, IT managers can monitor and configure printers remotely from a central office. Built-in RFID encoders support advanced tag pitches down to 16mm, saving media costs. This makes the ZT600 Series the premier choice for manufacturing execution systems (MES) and global supply chains throughout Bangladesh.
Contact RFID Solution today for pricing, deployment support, and system integration.
| Category | ZT610 RFID (4″) | ZT620 RFID (6″) |
|---|---|---|
| Print Method | Thermal Transfer & Direct Thermal | Thermal Transfer & Direct Thermal |
| Resolution | 203 dpi (std) / 300 dpi (opt) / 600 dpi (opt) | 203 dpi (std) / 300 dpi (opt) |
| Max Print Width | 4.09″ (104 mm) | 6.6″ (168 mm) |
| Max Print Speed | Up to 14 ips (356 mm/sec) | Up to 12 ips (305 mm/sec) |
| Max Print Length | 150″ (203 dpi) / 130″ (300 dpi) / 30″ (600 dpi) | 150″ (203 dpi) / 100″ (300 dpi) |
| Memory (RAM) | 1 GB | 1 GB |
| Flash Memory | 2 GB Linear Flash | 2 GB Linear Flash |
| Operating System | Link-OS | Link-OS |
| Display | 4.3″ Full-Color Touch LCD | 4.3″ Full-Color Touch LCD |
| Construction | All-metal heavy-duty frame | All-metal heavy-duty frame |
| Media Sensors | Dual: Transmissive & Reflective | Dual: Transmissive & Reflective |
| Media Width (Tear/Cutter) | 1.0″ – 4.5″ | 2.0″ – 7.0″ |
| Media Width (Peel/Rewind) | 1.0″ – 4.25″ | 2.0″ – 6.75″ |
| Max Media Roll Diameter | 8.0″ (203 mm) | 8.0″ (203 mm) |
| Media Thickness | 0.0023″ – 0.010″ | 0.0023″ – 0.010″ |
| Media Types | Continuous, Die-cut, Black Mark, Notch | Continuous, Die-cut, Black Mark, Notch |
| Ribbon Length | 450 m (1476 ft) | 450 m (1476 ft) |
| Ribbon Width | 2.0″ – 4.33″ | 2.0″ – 6.85″ |
| Ribbon Core | 1″ (25.4 mm) | 1″ (25.4 mm) |
| RFID Technology | UHF EPC Gen2 V2.1 / ISO 18000-63 | UHF EPC Gen2 V2.1 / ISO 18000-63 |
| RFID Encoding | Adaptive Encoding Technology | Adaptive Encoding Technology |
| Connectivity (Std) | USB 2.0, RS-232, Gigabit Ethernet, Bluetooth 4.0 | USB 2.0, RS-232, Gigabit Ethernet, Bluetooth 4.0 |
| Operating Temp (TT) | 5°C – 40°C | 5°C – 40°C |
| Operating Temp (DT) | 0°C – 40°C | 0°C – 40°C |
| Humidity (Operating) | 20% – 85% Non-Condensing | 20% – 85% Non-Condensing |
| Electrical | 90–265 VAC, 47–63 Hz | 90–265 VAC, 47–63 Hz |
| Certifications | ENERGY STAR®, CE, FCC, IEC 60950 | ENERGY STAR®, CE, FCC, IEC 60950 |
